6

The range of available Toilet Care products may

vary for each country.

4 Use of your toilet



You can turn this bowl to a

desired position

(max. ±90 º). Close the

cover and use both hands

to rotate the bowl as

illustrated.



The toilet can be used with

the blade open or closed.

To open the blade, slide the

blade handle sideways as

illustrated. Make sure you

always close the blade

completely after use.

Electric Blade (if applicable)

Press the flush button to activate the

control panel. Then push the Electric Blade

button. The blade will open or close electrically.



Press the flush button once

to activate the control

panel. Then press the flush

button for several seconds

to flush the toilet.

Electric Ventilator (if applicable)

By activating the control panel, the

Electric Ventilator will start automatically; it will

shut off automatically after about 5 minutes.

The Electric Ventilator button will flash to

show that this function is active. To stop the

ventilator, press the Electric Ventilator button.

Press the button again to re-start the ventilator.

To optimise its function, activate the Electric

Ventilator before you use your toilet.

Ordinary toilet paper can

cause clogging. Use Aqua

Soft toilet paper instead. This

toilet paper is super-soft,

dissolves quickly, prevents

clogging and makes it easier to

empty the waste-holding tank.

Level indication

You can check wether your waste-holding tank has

a 1-level or a 3-level indication. Make sure the tank

is empty and place it back properly. Then activate

the control panel. If no level indication light lights

up, your toilet has a 1-level indication. It will only

indicate a full tank. If a green level indication light

immediately lights up, your toilet has a 3-level

indication. It will indicate empty, half full and full.

5 Emptying the tank

Waste-holding tank

When the red light of the level indicator on the

control panel lights up, you need to empty the

waste-holding tank. Remove the tank via the

service door. Then take it to an authorised waste

disposal point. Empty the waste-holding tank via

the pour out spout.

To empty the tank without splashing, press

and hold the vent button with your thumb

while the pour out spout is pointing downwards.

Waste Pump-Out system (if applicable)

By activating the control panel, this

button automatically lights up. Press the

button to empty the waste-holding tank into the

vehicle’s central waste tank. The button flashes

while the waste is being pumped and stops

flashing when all waste has been transferred.

(±1.5L of waste is left). If the central waste tank

is too full (only measured when this tank has a

level indicator), the button flashes rapidly and

no pump-out is possible until you have emptied

the central waste tank.

EN
