5

Box contents

• Soundbar

• Wireless subwoofer

• Remote control (inc. batteries)

• Power adapter

• 2 pin (type C) plug adapter

• 3 pin (type G) plug adapter

• EU AC power cable

• UK AC power cable

• HDMI cable

• Soundbar low feet (2 pcs)

• Soundbar wall-mount brackets (2 pcs)

• Soundbar wall-mount xings

• User manual

• Warranty card

Controls

Soundbar

(Refer to 1 on page 1)

1. – Switch the system between ON and STANDBY.

2.

– Select the source of audio (HDMI eARC/ARC, HDMI 1, HDMI 2,

USB, AUX IN, BT, OPTICAL).

3.

– Select Bluetooth mode. Press and hold to activate the pairing

function in Bluetooth mode or disconnect the existing paired

Bluetooth device.

4.

– Press to mute or resume the sound.

Long press to mute or unmute the rear speakers (if purchased

separately).

5.

– Reduce volume.

6.

– Increase volume.

(Refer to

2 on page 1)

1. DC IN – Socket for connecting power adapter (DC 22V, 2.1A).

2. Optical – Optical input port.

3. AUX IN – Connect to an external audio device.

4. USB – Insert USB ash drive to play music.

5. HDMI (1/2/eARC/ARC) – Connect HDMI TV (eARC/ARC) to your

TVs HDMI (eARC/ARC) port. Connect other devices to HDMI 1 / 2 to

pass-through to TV.

Subwoofer

(Refer to 3 on page 1)

1. PAIR indicator.

2.

button – Please refer to section "Subwoofer pairing".

3. AC IN power input.

Remote Control

(Refer to 4 on page 1)

1. – Switch the system between ON and STANDBY.

2.

– Select the source of audio (HDMI eARC/ARC, HDMI 1, HDMI 2,

USB, AUX IN, BT, OPTICAL).

3.

/ – Menu navigation. Adjust setting value.

4.

/ - Press to skip to previous/next track or long press to fast

rewind/fast forward in Bluetooth/USB source. Menu navigation.

5.

– Play/pause/resume playback in Bluetooth/USB source. Menu

selection.

6. – Cycle EQ presets..

7.

– Enter the soundbar menu.

8.

– Press to mute or resume the sound.

Long press to mute or unmute the rear speakers (if purchased

separately).

9.

/ – Press to activate bass level adjustment in custom EQ

preset.

10.

/ – Press to activate treble level adjustment in custom

EQ preset.

11.

/ – Increase/decrease the volume level.

Battery installation

1. To open the battery compartment, push your thumb down on to the

battery compartment cover and slide it down.

2. Fit two AAA batteries observing polarity +/- as shown. When

replacing the batteries, use only the same type of battery supplied.

3. Re-t the battery cover and clip it in place.

Soundbar front

(Refer to 5 on page 1)

1. Remote control sensor.

2. LED display.

Soundbar base

(Refer to 6 on page 2)

1. Wall-mount bracket screw locations.

Placement and mounting

Placement - soundbar

A If your TV is placed on a table or a wall, you can place the soundbar

on a at surface in front of or underneath the TV, centred with the

TV screen.

B If your TV has a centre-mounted stand, you can consider to use the

pre-tted high feet to elevate the soundbar over all or part of the

TV stand. This feature has been designed for use with Sharp EQ and

FQ series TVs and compatibility with other models and brands is not

guaranteed.

C If your TV is attached to a wall, you can mount the soundbar on the

wall directly below the TV screen, centred with the TV screen using

the included wall-mount kit.

Wall mounting (if using option-C)

(Refer to 7 on page 2)

• Installation must be carried out by qualied personnel only. Incorrect

assembly can result in severe personal injury and property damage

(if you intend to install this product yourself, you must check for

installations such as electrical wiring and plumbing that may be

buried inside the wall). It is the installer’s responsibility to verify that

the wall will safely support the total load of the soundbar and wall

brackets.

• Install the Soundbar so the top of the soundbar is at least 100 mm

below the bottom of the TV.

• Additional tools (not included) are required for the installation.

• Do not overtighten screws.

• Keep this instruction manual for future reference.

• Use an electronic stud nder to check the wall type before drilling

and mounting.
